220V 400W AC Servo Motor with Controller | PMSM Motor
Compact 220V 400W AC servo motor with intelligent controller, delivering smooth torque, precise 100–3000 rpm speed adjustment, and high efficiency. Ideal for CNC machines, conveyors, and automation systems.
Product Highlights
Stable Torque Control
PMSM design ensures smooth torque output and precise motion control across all speeds.
Wide Speed Range
Adjustable from 100 to 3000 rpm, suitable for automation and CNC equipment.
High Efficiency & Protection
Built-in protection against overheat, overcurrent, and short circuit for reliable long life.
Easy Digital Control
LED display with knob and FWD/REV switch for intuitive operation.
-
Description
-
Specifications
Overview
The HS60 220V 400W AC Servo Motor is a high-performance motion control solution integrating PMSM (Permanent Magnet Synchronous Motor) technology with an intelligent digital controller. It provides precise speed control, stable torque, and smooth acceleration for industrial automation and manufacturing systems.
This model features encoderless vector control, achieving servo-grade performance without an encoder while maintaining consistent speed and torque regulation. Its design combines the advantages of servo precision and cost-effective PMSM efficiency.
With low noise, high reliability, and multiple protection functions, this motor and controller set is suitable for conveyors, CNC machines, robotic platforms, and other automated systems.
For flexible installation and transmission setups, the HS60 motor can be paired with:
- ⚙️ AC Gear Motor with NMRV Worm Gear Reducer – right-angle gearbox for compact installation and high torque output.
- 🌌 Planetary Gearbox – precision gearbox for high-torque and space-saving automation designs.
Key Features
- 🔸 Rated Voltage: 220V AC
- 🔸 Rated Power: 400W
- 🔸 Rated Speed: 3000 rpm
- 🔸 Rated Torque: 1.27 N·m
- 🔸 Peak Torque: 3.9 N·m
- 🔸 Rated Current: 1.3A
- 🔸 Frame Size: 60×60 mm
- 🔸 Insulation Class: F
- 🔸 Protection Grade: IP65
- 🔸 Operating Temperature: -20°C ~ +40°C
Applications
- 🏭 Industrial automation systems
- 🤖 CNC machines and robotic arms
- 📦 Packaging and conveyor machinery
- ⚙️ Inspection and testing equipment
- 🔩 OEM and customized motion control projects
Specifications
| Model | HS60-400W |
|---|---|
| Rated Power (kW) | 0.4 |
| Rated Voltage (V) | 220 |
| Rated Current (A) | 1.3 |
| Rated Speed (rpm) | 3000 |
| Rated Torque (N·m) | 1.27 |
| Peak Torque (N·m) | 3.9 |
| Protection Grade | IP65 |
| Insulation Class | Class F |
| Weight (kg) | 1.2 |
| Ambient Temp | -20°C~+40°C |
