24V 400W High Torque Brushless DC Gear Motor
High-torque 24 V 400 W brushless DC gear motor with precise speed control and quiet, reliable operation.
Ideal for AGV, conveyors, robotics, and industrial automation equipment.
Product Highlights
High Torque Output
Delivers up to 22.3 N·m torque at 125 rpm with stable, efficient transmission
Variable Speed Control
Adjustable speed when paired with a compatible 24 V BLDC controller
Energy Efficient
Brushless motor design minimizes heat, reduces power loss, and extends service life
Compact Structure
Space-saving integrated gearbox ideal for automation and AGV applications
-
Description
-
Specifications
Overview
The 24V 400W Brushless DC Gear Motor delivers high torque, stable speed, and excellent efficiency for compact automation systems. It combines a durable BLDC motor with a precision gearhead for smooth power transmission and long service life.
When paired with a compatible 24 V BLDC controller, it enables precise variable-speed adjustment and energy-saving operation. Thanks to its compact structure, low noise, and reliable performance, it is widely used in AGVs, conveyors, robotics, and motion-control equipment.
Key Features
- Rated Power: 400 W with high torque and stable output performance
- Compact Design: Ideal for installations with limited space
- Variable Speed Control: Available through compatible 24 V BLDC controller
- High Efficiency: Low temperature rise during continuous operation
- Maintenance-Free: Long service life and smooth rotation
- Low Noise & Vibration: ≤ 57 dB(A) @ 1 m
- Wide Gear Ratio Range: 1:3 – 1:1200 for flexible speed and torque options
- Custom Options: Flange, shaft length, and brake available for OEM integration
Applications
- Automated Guided Vehicles (AGV) and robotics drive modules
- Industrial automation and packaging machinery
- Medical and laboratory automation devices
- Solar tracker and linear actuator systems
- Automatic door and access control mechanisms
- Custom OEM machines and equipment
Specifications
| Item | Description |
|---|---|
| Model | BL09FA-24V + 5GU20KB Gearhead |
| Rated Voltage | 24 V DC |
| Rated Power | 400 W |
| Motor Rated Speed | 2500 ± 8 % rpm |
| Motor Rated Torque | 1.53 N·m |
| Gear Ratio (example) | 20 : 1 |
| Output Speed (20 : 1) | 125 ± 8 % rpm |
| Output Torque (20 : 1) | 22.338 N·m |
| Noise | ≤ 57 dB(A) @ 1 m |
| Protection Grade | IP44 |
| Insulation Class | Class B |
| Ambient Temperature | −10 °C ~ +40 °C |
| Motor Life | > 8000 hours (continuous rating) |
| Mounting Direction | Horizontal or vertical |
| Optional Features | Encoder, brake, custom flange & shaft |
Note: Other gear ratios (1:3 – 1:500) are available; speed and torque scale proportionally.
