180W 220V AC Variable Speed Gear Motor | 6IK180RGN-CF
The 180W single-phase AC gear motor offers smooth speed control (90–1350/1650 r/min), reversible rotation, and rugged aluminum housing. Compatible with 5GN/5GU gearheads (ratios 3–200) and US-52 / UX-52 controllers, it delivers up to 520 kg·cm torque for compact automation.
Product Highlights
180W Output Power
Provides high torque and smooth adjustable speed for conveyors, packaging, and automation lines.
Compact Frame Size
104×104mm aluminum housing offers excellent heat dissipation and long service life.
Dual Voltage Options
Available in AC 110V and 220V versions to match different equipment requirements.
Smooth Speed Regulation
Works with US-52 or UX-52 controllers for precise and stable speed adjustment.
-
Description
-
Specifications
Overview
⚙️ The 180W single-phase AC gear motor delivers strong torque and reliable speed regulation for compact automation equipment.
It supports clockwise/counterclockwise rotation with a smooth control range of 90–1350 r/min @50Hz and 90–1650 r/min @60Hz.
The motor adopts a durable aluminum alloy housing for excellent heat dissipation and long service life. When paired with a US-52 / UX-52 type speed controller, it enables precise speed tuning, soft start & slow stop.
Key Features
- 🌀 Wide Speed Range – 90–1350 r/min (50Hz) / 90–1650 r/min (60Hz)
- 🔁 Reversible Operation – Supports both CW & CCW rotation
- 🔌 Voltage Options – AC 110V (AF) / AC 220V (CF), 50/60Hz
- 🧱 Rugged & Compact – Aluminum housing, long service life
- 🎛️ External Speed Controller – Adjustable speed, soft start & slow stop
- ⚙️ Gearbox Compatibility – Works with 6GN/6GU gearheads; common ratios 3–200
Applications
- 🏭 Small conveyors and production lines
- 📦 Packaging and labeling machinery
- 🧵 Textile & spinning machines
- 🔬 Laboratory automation devices
- 🛠️ Machine tools and testing equipment
- 🚗 Automotive fixtures & welding jigs
Specifications
| Model | 6IK180RGN(GU)-AF | 6IK180RGN(GU)-CF |
|---|---|---|
| Output Power | 180W | 180W |
| Voltage | AC 110V | AC 220V |
| Frequency | 50/60Hz | 50/60Hz |
| Poles | 4 | 4 |
| Rated Speed (r/min) | 1300 / 1600 | 1300 / 1600 |
| Speed Control Range (r/min) | 90–1350 @50Hz / 90–1650 @60Hz | 90–1350 @50Hz / 90–1650 @60Hz |
| Starting Torque (kg·cm) | 10.2 | 10.2 |
| Rated Torque (kg·cm) | 9.5 | 9.5 |
| Rated Current (A) | 2.6 | 2.6 |
| Capacitor (μF / V) | 30 / 250V | 10 / 450V |
| Motor Type | Single-phase AC induction gear motor (external speed controller) | |
| Controller Function | Adjustable speed, soft start & slow stop | |
| Shaft Options | Round shaft / Keyed shaft | |
| Cooling / Protection / Insulation | Natural air cooling / IP40–IP54 (by model) / Class B–F | |
| Rated Time | Continuous | |
Gearbox and Performance (with 6GN / 6GU)
| Reduction Ratio | 3 | 5 | 10 | 20 | 30 | 50 | 75 | 100 | 150 | 200 |
|---|---|---|---|---|---|---|---|---|---|---|
| Output Speed (r/min, 50Hz) | 500 | 300 | 150 | 75 | 50 | 30 | 20 | 15 | 10 | 7.5 |
| Output Speed (r/min, 60Hz) | 600 | 360 | 180 | 90 | 60 | 36 | 24 | 18 | 12 | 9 |
| Max Torque (kg·cm) | 32.8 | 54.6 | 108.7 | 210.6 | 300 | 360 | 520 | 520 | 520 | 520 |
All 180W AC variable speed motors from OUBANG Motor are compatible with 5GN and 5GU gearheads, supporting gear ratios up to 1:200 and delivering up to 520 kg·cm of torque for low-speed, high-load applications.
